MOPA MFPT 300C
A 300W, CE-certified miniaturized pulsed fiber laser delivering M² ≤1.4 beam quality for marking, engraving, and micro-cutting.
MOPA MFPT 300C Pulsed Fiber Laser
The MFPT 300C shares the MFPT 300M's 300W output, beam quality (M² ≤1.4), 319 × 265 × 100mm chassis, and up-to-15mJ single pulse energy range, built for the same higher-throughput marking, engraving, and precision cutting work.
Output is tunable from 10% to 100% of rated power, with a repetition rate range of 1 to 8000kHz for switching between surface marking, micro-cutting, and low-spatter welding without changing hardware. It offers a choice of fixed isolator or QCS quick-connect fiber output, runs on air cooling, drawing 1000W from a 24VDC supply — more than the MFPT 300M's 900W — and ships CE-certified with a 2-year standard warranty, extendable up to 5 years.
Key Features
A beam quality of M² ≤1.4 keeps the focused spot fine and consistent, for legible marks and clean engraved detail.
Single pulse energy up to 15mJ gives the MFPT 300C enough energy per pulse for precision work like paint removal, rust removal, and battery tab cutting.
Tunable heat input lets the MFPT 300C switch between surface marking, micro-cutting, and low-spatter welding without swapping hardware.
Available with a fixed isolator output or a QCS quick-connect output, for flexibility in how the laser integrates into a production line.
Runs on air cooling rather than a closed water loop, simplifying installation for bench-top, mobile, or OEM integration.
At 319 × 265 × 100mm and roughly 8kg — the same chassis as the rest of this group — the MFPT 300C draws the most power of the MFPT 200M/300M/200C/300C group at 1000W, to reach the same 300W output as the MFPT 300M.
Application Examples
Product Comparison
Select products from the dropdown options below to compare parameters and find your perfect laser.
| Product type | |
| Series | |
| Nominal power | |
| Module | |
| Polarization | |
| Power Redundancy | |
| Power Tunability | |
| Wavelength | |
| Power Stability | |
| Modulation Frequency | |
| Pulse Energy (mJ) | |
| Repetition Rate (kHz) | |
| Fiber Connectors | |
| Certifications and Safety | |
| Cooling Method | |
| Housing form | |
| Warranty | |
