M Series MFMC 80000M
An 80kW multi-module fiber laser delivering BPP 5.5–6.6 mm·mrad beam quality, CE-certified for cutting and welding.
M Series MFMC 20000 Industrial Fiber Laser
The MFMC 80000M is the lower-power model in the M Series' top multi-module tier, combining multiple laser modules into a single 80kW output for the highest-throughput cutting and welding work in the range. It runs in CW or modulated operating modes, with beam quality of BPP 5.5–6.6 mm·mrad through a 150μm fiber core, shared with the MFMC 85000M.
Output is tunable from 10% to 100% of rated power, with power stability holding within ±1% over an hour of continuous running. It connects over digital I/O, draws up to 280kW from a 400V three-phase supply, and ships CE-certified with a 3-year standard warranty.
Key Features
A beam parameter product of 5.5–6.6 mm·mrad through a 150μm fiber core keeps output consistent at the top of the M Series' power range.
Runs in continuous-wave or modulated mode, giving flexibility to match output delivery to the cutting or welding process at hand.
Output is adjustable from 10% to 100% of rated power, with modulation up to 5kHz, for dialing in exactly the energy a given material or joint calls for.
Digital I/O connectivity drops the MFMC 80000M into existing cutting and welding cells without custom middleware.
Multiple laser modules are combined into a single cabinet enclosure, giving the MFMC 80000M its 80kW output in one integrated unit.
At 1100 × 2185 × 1610mm and roughly 1900kg — identical to the MFMC 85000M — the MFMC 80000M shares its top-tier chassis with no weight or footprint difference between the two, only power.
Application Examples
Product Comparison
Select products from the dropdown options below to compare parameters and find your perfect laser.
| Product type | |
| Series | |
| Nominal power | |
| Module | |
| Polarization | |
| Power Redundancy | |
| Power Tunability | |
| Wavelength | |
| Power Stability | |
| Modulation Frequency | |
| Pulse Energy (mJ) | |
| Repetition Rate (kHz) | |
| Fiber Connectors | |
| Certifications and Safety | |
| Cooling Method | |
| Housing form | |
| Warranty | |
