MOPA MFPT 2000M
A 2000W, CE-certified water-cooled pulsed fiber laser delivering up to 100mJ single pulse energy for heavy-duty industrial cleaning.
MOPA MFPT 2000M Pulsed Fiber Laser
The MFPT 2000M tops out this group at 2000W, sharing the same 482.6 × 681.5 × 172mm chassis, dual single pulse energy option (50mJ or 100mJ), and choice of 300μm or 400μm fiber core as the MFPT 1000M, with more power in reserve for heavier-duty or higher-throughput cleaning runs.
Output is tunable across a 1ns (CW) to 500ns pulse width range, running in CW or pulsed mode depending on the job — CW mode also suits precision welding work alongside its main industrial cleaning applications — with a repetition rate adjustable from 10 to 3000kHz. It connects via QBH fiber output over a 10m cable, runs on water cooling — circulating distilled water or a glycol antifreeze mix — draws up to 8000W from a 380VAC supply, and ships CE-certified with a 2-year standard warranty, extendable up to 5 years, weighing roughly 52kg with its armored cable.
Key Features
A choice of 50mJ (M² ≤10) or 100mJ (M² ≤25) single pulse energy, the same range as the MFPT 1000M, for cleaning jobs that need more energy per pulse than the MFPT 500M offers.
Available with a 300μm or 400μm output fiber core, for tuning beam size to the job.
Built for high-throughput industrial cleaning: laser cleaning of tires, cleaning industrial molds, and roughening surfaces ahead of coating or bonding.
Adjustable from 10 to 3000kHz, the same range as the MFPT 500M and MFPT 1000M, for fine control over cleaning speed and coverage.
Runs on water cooling — circulating distilled water or a glycol antifreeze mix — to sustain output at higher power over long cleaning runs.
At roughly 52kg and drawing up to 8000W, the MFPT 2000M is the highest-power model of the MFPT 500M / 1000M / 2000M group.
Application Examples
Product Comparison
Select products from the dropdown options below to compare parameters and find your perfect laser.
| Product type | |
| Series | |
| Nominal power | |
| Module | |
| Polarization | |
| Power Redundancy | |
| Power Tunability | |
| Wavelength | |
| Power Stability | |
| Modulation Frequency | |
| Pulse Energy (mJ) | |
| Repetition Rate (kHz) | |
| Fiber Connectors | |
| Certifications and Safety | |
| Cooling Method | |
| Housing form | |
| Warranty | |
